SimpliFire Allusion 40" Linear Electric Recessed Fireplace
SimpliFire Allusion 40" Linear Electric Recessed Fireplace
Media Option
Trim Kit
-- Please Select --
No, Thank You
Couldn't load pickup availability
- Free Shipping on Orders Over $300
- Same-Day Order Processing
The Allusion electric fireplace series embraces modern design by combining linear proportions with a multitude of flame and ember bed LED lighting themes. Additionally, intuitive operation is exemplified by the standard remote and touch controls on the fireplace front.
What's Included
- Clear Crystal Media
- Remote Control and Receiver
- Heater and Motor
- Glass Front
- Bracket and Hardware Kit
- LED Assembly
- Rotisserie
- PCB Board Assembly
Not Included (Sold Separately)
- Ceramic White Stone Media
- Driftwood Logs
- Trim Kit
Features
- Available in 40, 48”, 60” and 84” wide models
- Four flame color themes
- Tailor each fireside experience with four flame and 13 ember-bed color choices.
- Simple touch controls on the fireplace front for added convenience
- Clear crystal media creates the illusion of a soothing fire rising from a lighted ember bed
- Intuitive, multi-function remote for control at your fingertips
- Adjustable heat that costs just pennies an hour to operate
- Zone heat your space to remain comfortable while reducing your monthly bills
- Multi-function remote - Thermostat, lighting, on/off control at your fingertips.
Installation Type
- Fully Recess - Provides a clean look that is fully recessed on a finished 2 x 6 wall; is removable for easy relocating.
- Wall Mount - Facilitates fast and easy installation with a simple wall mount kit for easy placement.
- Partially Recess - Installs on a 2 x 4 framed wall with 2" protrusion and is removable for easy relocating.
Specifications
| Models | SF-ALL40-BK |
| Appliance Dimensions Front | 40.5" (W) x 5.9375" (D) x 20.25" (H) |
| Appliance Dimensions Back | 35" (W) x 17.8125" (H) |
| Viewing Area | 31.375" (W) x 11.25" (H) |
| BTU Output | up to 5,000 |
| Vent Type | Vent-Free |
| Finish | Black |
| Style | Contemporary |
| Fuel Type | Electric |
| Heating Area | 400 sq. ft. |
| Volts | 120V |
| Watts | 1500W |
| Amperage | 12.5 amps |
| Installation Type | Full Recess / Partial Recess / Wall Mounted |
| Thermostat Mode | YES |
Technical Drawings and Dimensions
| Model | A | B | C | D | E | F x G |
| SF-ALL40-BK | 40-1/2" | 35" | 20-1/4" | 17-13/16" | 5-15/16" | 31-38" x 11-1/4" |
| Framing Dimensions | Width | Height | Depth |
| 36" |
18-1/8" |
2" x 6" |
Warranty
 |
2-Years Warranty All parts except as covered by Warranty Conditions, Warranty Exclusions, and Warranty Limitations listed |
Warranty Coverage
HHT warrants that the Products and their Component Parts will be free from defects in materials and workmanship for the applicable period of Warranty coverage set forth in the table below (“Warranty Period”). If a Product or Component Parts are found to be defective in materials or workmanship during the applicable Warranty Period, HHT will, at its option, repair the applicable Component Part(s), replace the applicable Component Part(s), or refund the purchase price of the applicable Product(s). The maximum amount recoverable under this Warranty is limited to the purchase price of the Product. This Warranty is transferable from the original purchaser to subsequent owners, but the Warranty Period will not be extended in duration or expanded in coverage for any such transfer. This Warranty is subject to conditions, exclusions, and limitations as described below.
Click to See Warranty Period and Limitations
Warranty Period
Warranty coverage begins at the date of installation. In the case of new home constructions, Warranty coverage begins on the date of first occupancy of the dwelling or six months after the sale of the Product(s) by an independent, authorized HHT dealer or distributor, whichever occurs earlier. However, the Warranty coverage shall commence no later than 24 months following the date of Product shipment from HHT, regardless of the installation or occupancy date. The term “Lifetime” in the table below is defined as: 20 years from the beginning date of warranty coverage for gas appliances, 10 years from the beginning date of warranty coverage for wood and pellet appliances, and 5 years from the beginning of warranty coverage for standalone gas log sets. These time periods reflect the minimum expected useful lives of the designated Component Parts under normal operating conditions.
Warranty Limitations
EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. The owner’s exclusive remedy and HHT’s sole obligation under this Warranty or in contract, tort or otherwise, shall be limited to replacement of the Component Part(s), repair of the Component Part(s), or refund of the original purchase price of the applicable Product(s), as specified above; provided, however, that (i) if HHT is unable to provide replacement of the Component Part(s) and repair of the Component Part(s) is not commercially practicable or cannot be timely made, or (ii) the customer is willing to accept a refund of the purchase price of the applicable Product(s), HHT may discharge all such obligations by refunding the purchase price of the applicable Product. In no event will HHT be liable for any incidental or consequential damages caused by defects in the applicable Product. Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This Warranty gives you specific legal rights and you may also have other rights which vary from State to State. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE FOR THE APPLICABLE PRODUCT. Some States do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
